Program of Color Science/Munsell Color Science Laboratory

Overview

faculty and student taking picture of a large abstract paintingThe Munsell Color Science Laboratory and the Program of Color Science unite to form one of the world‘s foremost color science research and education organizations. Our mission is to provide world-class education, research, and outreach in all areas of color science including:

  • Physical spectral and colorimetric measurements of materials and light sources.
  • Understanding the capture, processing, and display of color and spectral power distributions.
  • Quantifying the human sensation of color matches and the higher-level perceptions of color appearance and chromatic adaptation.

These areas, and others, are studies from the perspectives of both fundamental scientific disciplines such as physics, chemistry, biology, mathematics, and psychology and application areas including:

  • Imaging Science
  • Motion Picture Science
  • Computer Science
  • Computer Graphics
  • Museum and Conservation Science
  • Sustainability

Follow us on Instagram @rit_pocs_mcls

History of the Munsell Color Lab

The Munsell Color Company was founded by Professor Albert H. Munsell, the creator of the Munsell Color Order System and the Munsell Book of Color. The directors of the Munsell Color Company eventually sold the company's assets and created the Munsell Color Foundation. The Foundation was charged with furthering the scientific and practical advancement of color knowledge.

In 1983, the Foundation trustees voted to dissolve the foundation, and donate the proceeds to an academic institution for the creation and endowment of the Munsell Color Science Laboratory. RIT was selected as the recipient of this donation, and MCSL was born. (Note: There is no formal relationship between the RIT Munsell Color Science Laboratory and the commercial Munsell Color products sold by X-Rite.)

The creation of MCSL was in large part due to the efforts of Franc Grum, the first MCSL Director (currently Prof. Mark Fairchild) and R.S. Hunter Professor of Color Science, Appearance, and Technology (currently Prof. Roy Berns). Prior to founding MCSL and RIT’s Department of Color Science, Professor Grum was a member of the Munsell Color Foundation, long-standing friend of RIT as an employee of the Eastman Kodak Research Laboratories, and an Adjunct Professor in the Photographic Science Department.

Initially, MCSL and the Color Science Department were part or RIT's College of Graphics Arts and Photography. RIT later created the Chester F. Carlson Center for Imaging Science, and MCSL became a research laboratory within that Center, currently housed in RIT's College of Science. In 1989, MCSL and the Center for Imaging Science moved to a new facility with approximately 6,500 square feet of space dedicated to color science research and education.

In the spring of 2003, space opened up in a nearby building. After extensive renovations, MCSL and the Color Science program moved into what is now formally called the Color Science Hall. The collocation of all our offices and laboratory space has fostered an amazing collaborative spirit in what was already an exciting, cooperative organization.

After careful strategic review of color science at RIT, the Program of Color Science (PoCS) and Munsell Color Science Laboratory (MCSL) were more closely joined as a stand-alone multidisciplinary graduate program in the College of Science. This new chapter in the storied history of these programs began in 2013, 30 years after the lab’s founding, with an aim of further extending the reach of color science across more scientific disciplines and into even more application areas.

"Nulli Secundus"

The Franc Grum Memorial Scholarship was established after his untimely death in 1985. It is intended to support scholarship in optical radiation measurements and color science. The funds for this award were made possible by gifts from the friends and family of Franc, as well as from industry.

Year Recipient Current Employer
1988 Mark E. Gorzynski Hewlett-Packard
1990 Michael Stokes Microsoft
1992 Audrey Lester Xerox
1994 Richard L. Alfvin Eastman Kodak
1997 Garrett M. Johnson Apple
2000 Mark Q. Shaw Hewlett-Packard
2001 Scot R. Fernandez Hallmark
2004 Justin L. Laird Gunlocke
2008 Erin Fredericks ITT

About Albert H. Munsell

Photo of Albert MunsellProfessor Munsell was born in Boston, Massachusetts on January 6th, 1858 and died June 28th, 1918 at age 60. Author of A Color Notation (1905) and the Atlas of the Munsell Color System (1915). Both an artist of distinction and a gifted teacher of art, he developed the first widely-accepted color order system to make the description of color accurate and convenient and to aid in the teaching of color. The Munsell color order system has gained international acceptance and has served as the foundation for other color order systems.

Albert Munsell founded the Munsell Color Company in 1917. Later, in 1942, the Munsell Color Foundation was formed by the company to promote the advancement of the science of color. Ultimately, the Munsell Color Foundation led to the founding of this laboratory, the Munsell Color Science Laboratory, in 1983, at the Rochester Institute of Technology.

Related Scholarly Research and Imagery

Unfortunately, no high-quality photo of Professor Munsell is available. In 1998, Munsell graduate student Doug Corbin restored the photo from Munsell's book, A Color Notation. The details of the procedure appeared in the February 1999 issue of Color Research and Application. Doug has provided the following information pertaining to this restoration:

The full text of the CR&A submission can be found here.
The LARGE uncorrected image can be found here. (21MB TIFF file)
The scientific diaries of Albert Munsell are available here.

For some other insights into the work of Professor Munsell, here is a self-published work form 1907 entitled, "Color and an Eye to Discern it." This was provided by Rolf Kuehni, who originally retrieved it from The Hagley Museum and Library.



Graduate Programs

The Master of Science and Ph.D. color science programs explore all aspects of color, from lighting, through material properties, to human perception. The program is closely associated with the Munsell Color Science Laboratory, which is considered one of the world’s top research facilities in the science of color.

Understand how humans perceive and interact with color in this unique program that has limitless applications.

Learn More about Color Science MS

Color has been an intense topic of interest for thousands of years. Mathematicians, philosophers, physicists, physiologists, poets, and other disciplines have all contributed to our understanding of color. RIT’s color science Ph.D. program allows you to contribute to knowledge creation and practical application of color science. You will conduct extensive research that encompasses diverse fields and multiple disciplines of science. The program is designed for students whose undergraduate degrees are in physics, biology, chemistry, mathematics, computer science, engineering, neuroscience, experimental psychology, imaging, or any applied discipline pertaining to the quantitative description of color.

Learn More about Color Science Ph.D.

Educational Resources

These files are available for download. All come "as is." We have found them useful, and done our best to ensure their accuracy. If you find out otherwise, please let us know.

Instrument Evaluation Database
This is a database of instrument evaluation files. These data accompany a pair of 2007 articles in Color Research and Application. These files are available for download. Most are in Microsoft Excel format.

In all files, instruments are identified only by letter. The classes of instruments are:

  • Handheld hemispherical instruments: A,B,C,D
  • Benchtop hemispherical instruments: E,F,G,H
  • Bidirectional instruments: I,J,K,L
  • Additionally, there are two pairs of identical models: A and B, and K and L.
  • All colorimetric data are calculated using D65 and the 10° standard observer

Short-Term Repeatability Data

  • 50 repeated measurements without replacement
  • Pressed PTFE (spectral and colorimetric data)
  • Glossy White Tile (spectral and colorimetric data)
  • Individual instrument files (PTFE and glossy tile): ABCDEFGHIJKL

Medium-Term Repeatability Data

  • 10 measurements per hour for eight hours
  • Pressed PTFE (colorimetric data)

Long-Term Repeatability Data

  • 2 measurements per day for five weeks
  • samples include: glossy and diffuse whites, cyan BCRA tile, cyan printed ink
  • Pressed PTFE (spectral data) Note: worksheets are labeled by instrument number. An X indicates incomplete data.

MetaCow Spectral Image Database
METACOW: A Public-Domain, HighResolution, Fully-Digital, Noise-Free, Metameric, Extended-Dynamic-Range, Spectral Test Target for Imaging System Analysis and Simulation

Standard, easily accessible, test targets have long served the field of color imaging as a foundation for comparison of the performance of various imaging systems and algorithms and the open and meaningful exchange of research results. This website details the creation and application of a new digital color test target useful for research and development of color imaging systems. The target has several advantages over previous types of targets that include spatial resolution, dynamic range, spectral resolution, metameric properties, lack of noise, and continuous tonal variations. All these features can be important for visual assessment, computational analysis, and colorimetric evaluation. This target, known as METACOW, is freely available to all performing research in color imaging.

METACOW is basically a very large (4200 x 6000 pixel) full-spectral image. It is rendered at 5nm increments, between 380 to 760...and is thus about 3gigs in size. It is designed such that both halves of each "cow" appear to match when illuminated with CIE D65, and viewed with the CIE 1931 Standard Observer. This is the example shown above. Each half of the cow is actually maximally metameric with itself. The left half of each cow has the spectral reflectance of the GretagMacbeth Color Checker, while the right half is a Metameric black that has been specially calculated to maximize color difference under Illuminant A. This type of target is designed to test both illumination and spectral responsivities for digital imaging solutions. Examples of illuminant (left) and observer (right) metamerism are shown below.

cow images in a spectrum of colorsThe image on the top was rendered under Illuminant A with the CIE 2 degree Observer, and then converted to display sRGB using the CIECAT02 chromatic adaptation transform. The image on the bottom was rendered under D65 with actual digital camera spectral sensitivities. The metameric nature of the METACOW target should be readily apparent from these examples.

The METACOW test target available for download, for use in imaging system design and evaluation. We ask only that you credit the Munsell Color Science Laboratory in any publications. Note that it is a large image; make sure you are on a decent internet connection for the download. Included in the files are: many GB of fullsize METACOW Glory, Smaller and Easier to Manage MINIMETACOW, Matlab Source Code for Reading and Rendering METACOW, and Much More. Or you can download a smaller version (420x600x77).
Small METACOW Images
Large METACOW Images (500MB file!)

Lippman2000 Spectral Imaging Database
This project is named Lippmann2000 in honor of Gabriel Lippmann who in 1891 devised a method to perfectly reconstruct the spectral content of real world scenes. In spite of Lippmann's invention, a more primitive three-channel model, first demonstrated by James Clerk Maxwell 30 years prior, has dominated the color imaging field. The Maxwellian model, universal in today's color image capture systems, relies on the metameric properties of the human visual system to simulate the appearance of an original color. The capture of full spectral data, while holding advantage over traditional three-channel methods offers new challenges at every point in the imaging chain.

PLEASE NOTE: THESE IMAGES ARE MADE AVAILABLE FOR RESEARCH PURPOSES ONLY. All other uses are prohibited. Copyright remains with PoCS / MCSL.

Overview and History

squares of different black and red huesIn the 1940's the color science community recognized that the most visually-uniform color space to date, the Munsell Color Order System, had inconsistencies that required examination and remedy. Towards this goal, a large-scale visual experiment was taken with many observers across several continents. The results amounted to an adjustment of the target color coordinates for the Munsell colors. The files here reflect that correction.

There are three files available for download. All are of the same format: six columns of Munsell hue, Munsell value, Munsell chroma, CIE x, y, and Y. The chromaticity coordinates were calculated using illuminant C and the CIE 1931 2 degree observer.In a sense, all three files represent the same set of data, in that all depend on the scaling experiments of the late 1930's.

A report entitled "One Set of Munsell Re-renotations," by Deane B. Judd and Dorothy Nickerson was issues by the National Bureau of Standards (now NIST) in 1967. As the title implies, they proposed an alternative to the original renotation scheme. As far as we know, these did not receive much attention, and their utility is uncertain. The report and associated data table have been scanned. If you use this please let us know! We would be interested in any useful application of the report of data.

One important note is that these data are taken from Wyszechi & Stiles 2nd Ed (1982) and the value scale is base on the original fifth order polynomial (relating Y/Ymgo to V). Modern instruments rererence the perfecting reflecting diffuser, so you may have better results if your multiple the Y values in these tables by 0.975, which is Ymgo, the Y value for the smoked magnesium dioxide reference white.

NONE OF THESE DATA SHOULD BE CONFUSED WITH ACTUAL
MEASUREMENTS FROM A MUNSELL BOOK OF COLOR!

all.dat: real and unreal

File download: all.dat

These are all the Munsell data, including the extrapolated colors. Note that extrapolated colors are in some cases unreal. That is, some lie outsize the Macadam limits.

This file should be used for those performing multidimensional interpolation to/from Munsell data. You will need the unreal colors in order to completely encompass the real colors, which is required to do the interpolation when near the Macadam limits.

real.dat: by the book

File download: real.dat

These are real colors only, "real" being those lying inside the Macadam limits. Specifically, these are those colors listed the original 1943 renotation article (Newhall, Judd, and Nickerson, JOSA, 1943).

This file should be used for a complete mapping between the Munsell system and its CIE equivalents. Note, however, that many of these colors were not used in the original scaling experiments, and are therefore extrapolated or at best interpolated from the test colors used.

Flash! Here are sRGB values and CIELAB for most of the colors in the real.dat file. There are some important notes regarding these data in the spreadsheet.

1929.dat: back to the source

File download: 1929.dat

These are only those colors physically appearing in the 1929 Munsell Book of Color. These data might be of useful for those interested in the input colors used for the scaling experiments leading to the 1943 renotation. Remember though, these are renotation colors of those original patches, not necessarily the colors of the input data used in the visual experiment.

We are pleased to make these diaries available online. The links below are individual PDFs, each in the range of 0.5 to 1MB. They represent all of volumes A and B in approximately twenty page increments. The index pages list the names of people mentioned in the diaries. Sorry, but there is no subject index. If you would like to create one, we will gladly publish it here!

Note that some PDFs are actually more than 20 pages. We grouped the tiles by the page number in the typed copies. Many pages were inserted with letter notation (4a, 4b, 4c, etc). Also, some of the handwritten pages are unnumbered. You may want to download the document before or after to make sure you get the desired pages.

Volume A       Volume B

Part 1, pp 1-20



Part 1, pp 231-250

Part 2, pp 21-40



Part 2, pp 251-270

Part 3, pp 41-50



Part 3, pp 271-290

Part 4, pp 61-60



Part 4, pp 291-310

Part 5, pp 81-100



Part 5, pp 311-329

Part 6, pp 101-120



Part 6, pp 330-350

Part 7, pp 121-140



Part 7, pp 351-370

Part 8, pp 141-160



Part 8, pp 371-390

Part 9, pp 161-180



Part 9, pp 391-412

Part 10, pp 181-200



Part 10, pp 413-420

Part 11, pp 201-220



Part 12, pp 221-230





ORIGINAL COVER SHEET
Below is the text from the cover sheet in the diary binders as received. It was slightly edited for typographical errors.

The diary hereby made available is one kept by A. H. Munsell during the years in which he was developing both the Munsell color system and apparatus and charts by which to explain it.

A typewritten copy was made at the Munsell Color Company in the years 1920-23 from 6 volumes of a handwritten diary kept by Professor Munsell. Drawings and sketches were all hand-traced, and handwriting was inserted where corrections or additions were made in the original. Volume A covers the period 1899 through May 1908; volume B, May 1908 through 1918.

In 1939 the Inter-Society Color council, with permission from the Munsell family and company, deposited a bibliofilm negative of this typed material with the American Documentation Institute, their Document No. 1307. Early documents of this Institute now filed with the photo-Duplication Division of the Library of Congress, Washington, D.C., from which photoprints of microfilm positives may be ordered.

This copy of the Munsell Diary is one of three photocopied by Hunter Associates Laboratory in the spring of 1973 from the original typed copy loaned to Dorothy Nickerson by the Munsell Color Company. The three copies are filed with Miss Nickerson, the Rochester Institute of Technology through Milton Person (these copies are now at the Munsell Color Science Laboratory), and the Hunterlab library.

Reports of the development and application of the Munsell Color Systems since 1918 are available in the two historical papers by D. Nickerson: 1940, Journal of the Optical Society of America, 30, 575-586; 1969, Color Engineering, 7, 42-51.

Hunter Associates Laboratory, Inc.
Fairfax, VA. 22030
June, 1973

These files are available for download. All come "as is." We have found them useful, and done our best to ensure their accuracy. If you find out otherwise, please let us know.

CIE Standard Colorimetric Observer Data

  • 1931 2° CIE Standard Colorimetric Observer Data
  • 1964 10 °CIE Standard Colorimetric Observer Data
  • Excel spreadsheet


CIE Standard Illuminant Data

Full set of 1nm data, including all of the following:

  • Illuminant A
  • Illuminant D65
  • VM(λ) 1988 Spectral Luminous Efficiency Function for photopic vision
  • V'(λ) Spectral Luminous Efficiency Function for scotopic vision
  • 1931 2° CIE Standard Colorimetric Observer Data
  • 1964 10 °CIE Standard Colorimetric Observer Data
  • Excel with all of the above


Spectral Data for Commonly Used Color Products

Code for CIE Color Difference formula CIEDE2000

Note: The above code was debugged to match the output of the Witt spreadsheet.

Pointer Data Set

  • This spreadsheet is available by permission from Dr Michael Pointer. These data are those on which the often cited paper was based. The original article is "The Gamut of Real Surface Colors", M.R.Pointer, Color Research and Application 5 (1980).
  • Excel Spreadsheet, as provided by Dr. Pointer


CIE 170-1:2006 Cone Fundamentals for Various Field Sizes and Observer Ages

Planck's Blackbody Equation Enumerated

Color Science Research

RIT’s Program of Color Science and Munsell Color Science Laboratory have a rich history of education and research dating back over 30 years to the early 1980s. Well over 100 graduate-program alumni have helped produce about 1000 journal papers and conference proceedings in areas such as spectroscopic and colorimetric instrumentation, color modeling and formulation, chromatic adaptation and color appearance, color matching functions and metamerism, color difference perception and prediction, image perception and reproduction, measurement and conservation of cultural heritage, and many more.

Going forward, these research initiatives will be expanded in an even more multidisciplinary fashion. The program and lab will work closely with researchers in the fundamental scientific disciplines of biology (human and animal vision), chemistry (colorants and formulation), physics (optical spectroscopy and illumination sources), mathematics (modeling of systems and observers), and psychology (understanding color perception). In addition, and in step with RIT’s strong history in applied research, we will pursue the applications of color science to a wide variety of technology areas including photography, imaging, textiles, computing, materials, photonics, lighting, sustainability, systems engineering, architecture, packaging, printing, gaming, cinema, and design.

Please see the pages linked here for some archives of information from past student and faculty projects and visit the individual faculty web pages for more detailed research information and opportunities.

Each calendar year, the faculty, staff, and students of PoCS/MCSL gather some highlights of the past year into an annual report for our friends, supporters, alumni, and others. These reports also include a record of the journal publications, conference presentations, and other accomplishments of the group. They are also good references for lists of then-current students and a running list of MCSL alumni. Please take a moment to download and review our latest annual report (or historical reports dating back to the lab's founding).

Annual Report 2018
Annual Report 2017
Annual Report 2016
Annual Report 2015
Annual Report 2014
Biennial Report 2012-13
Annual Report 2011
Annual Report 2010
Annual Report 2009
Annual Report 2008
Annual Report 2007
Annual Report 2006
Annual Report 2005
Annual Report 2004
Annual Report 2003
Annual Report 2002
Annual Report 2001
Annual Report 2000
Annual Report 1999
Annual Report 1998
Annual Report 1997
Annual Report 1996
Annual Report 1995
Annual Report 1994
Annual Report 1993
Annual Report 1992
Annual Report 1991
Annual Report 1990
Annual Report 1989
Annual Report 1988
Annual Report 1987
Annual Report 1985-86
Annual Report 1984-85
